Identification: PS 1550
Capacity Kg: 1500
Min fork height mm: 85
Lifting height mm: 5000
Centre of gravity separation: 600
Min support height: 2220
Min support height: 5520
Total width mm: 1000
Total length mm: 2180
Free lift mm: 1660
Fork width mm: 570
Fork length mm:1150
Driving speed wit-hout/with load km/h: 6.0/5.9
Lifting speed without/with load mm/s: 212/141
Lowering speed wit¬hout/with load mm/s: 178/227
Electronics: Curtis
Drive motor: 1,5 kW
Lift motor: 3 kW
Truck battery: 310Ah/24V
Charger: 40Ah/24V (External)
Fork wheel mm: Polyurethane 80 x 70
Drive wheel mm: 230 x 75
Gradient capacity without/with load: 12/6 grader
Brake: Electromagnetic
Speed regulation: Electronic impulse
Weight kg including battery: 1596
Swing radius mm: 1806
Mast type: Duplex
Electric power stackers for the really high lifts with electronic power steering and stand on platform with side protections makes the working days easier and safer. It does not get easier to handle goods in tight warehouses with high racking than with this full electric pallet stacker with power steering. Strong and robust with crucial details for the convenience of the user.
